Product Name
Rods and Tubes
SKU
PTRIBT
Virgin PTFE Rods and tubes, the rod is a solid piece of PTFE while the tube has an inside and outside diameter ( hollow), due to the nature of Teflon it resists high temperatures and is anticorrosive. It is possible to produce Rods or tubes with the following characteristics in measurements. TUBES: outer diameter from 1 to 12 inches; inner diameter of 7 to 8 inches with a minimum length of 4" and a maximum of 15", in the case of Rods the same applies, only the inner diameter changes which would be solid.
Virgin PTFE Rods and tubes, due to the nature of Teflon it resists high temperatures and is anticorrosive.
| Name | Features | Description | Application/Industry |
|---|---|---|---|
| VIRGIN PTFE RODS AND TUBES | RIGID PIECE IN THE FORM OF A ROD/TUBE OF VIRGIN PTFE IN MEASUREMENTS BETWEEN 1" AND 24" IN DIAMETER AND BETWEEN 14" TO 20" IN LENGTH. | Virgin PTFE rods and tubes, ranging from 1” to 24” in diameter, length from 14" to 20" with a wide range of intermediate measurements, the rod is a solid piece of PTFE while the tube has an inside and outside diameter (hollow), due to the nature of Teflon it resists high temperatures and is anticorrosive. | Industry in general such as chemical, oil, electrical, paper, nuclear, metallurgical, automotive, aeronautics, pharmaceutical and food, among others. |
| PTFE RODS AND TUBES LOADED WITH FIVI (FIBERGLASS) | RIGID PIECE IN THE FORM OF A PTFE BAR/TUBE WITH FIBERGLASS IN MEASUREMENTS BETWEEN 1" AND 24" IN DIAMETER AND BETWEEN 14" TO 20" IN LENGTH. | Virgin PTFE or fiberglass filled rods and tubes, ranging from 1” to 24” in diameter, length from 14" to 20" with a wide range of intermediate measurements, the rod is a solid piece of PTFE while the tube has an inside and outside diameter (hollow). This mineral filler allows the piece to have superior compression and sliding properties. Improves the friction resistance of PTFE at high and low temperatures, excellent chemical stability, except strong alkalis and hydrofluoric acid, has better thermal conductivity and friction coefficient when combined with molybdenum disulfide or graphite. | It is the most common load for seals when there is rotation and alternation in movements (application in pneumatic, hydraulic use, bearings, piston rings, valve seats and mechanical parts). |
| PTFE RODS AND TUBES CHARGED WITH MoS2 (DISULPHIDE) | RIGID PIECE IN THE FORM OF A BAR/TUBE OF PTFE WITH DISULPHIDE IN MEASUREMENTS BETWEEN 1" AND 24" IN DIAMETER AND BETWEEN 14" TO 20" IN LENGTH. | Rods and tubes of virgin or disulfide-filled PTFE ranging from 1” to 24” in diameter, length from 14" to 20" with a wide range of intermediate measurements, the rod is a solid piece of PTFE while the tube has inner and outer diameter (hollow). WITH COMPRESSION QUALITIES | In dynamic seals where self-lubricity is important, it is generally combined with fiberglass or bronze (bearings, seal rings, piston rings). |
| GRAPHITE PTFE RODS AND TUBES | RIGID PIECE IN THE FORM OF A BAR/TUBE OF PTFE WITH GRAPHITE IN MEASUREMENTS BETWEEN 1" AND 24" IN DIAMETER AND BETWEEN 14" TO 20" IN LENGTH. | Virgin or graphite filled PTFE rods and tubes ranging from 1” to 24” in diameter, length from 14" to 20" with a wide range of intermediate measurements, the bar is a solid piece of PTFE while the tube has inner and outer diameter (hollow). WITH DRIVING QUALITIES | Widely used in seals where great wear resistance under high pressure is required (piston rings for non-lubricated compressors, bearings) |
| STAINLESS STEEL PTFE RODS AND TUBES | RIGID PIECE IN THE FORM OF A BAR/TUBE OF PTFE WITH STAINLESS STEEL IN MEASUREMENTS BETWEEN 1" AND 24" IN DIAMETER AND BETWEEN 14" TO 20" IN LENGTH. | Virgin or filled stainless steel PTFE rods and tubes ranging from 1” to 24” in diameter, length from 14" to 20" with a wide range of intermediate measurements, the bar is a solid piece of PTFE while the had It has an inner and outer diameter (hollow). WITH QUALITIES OF HARDNESS AND COMPRESSION | It is good in applications when high compression and chemical resistance is required, it is good in dynamic applications (seals and bearings for certain machinery in the food industry). |
| CARBON PTFE RODS AND TUBES | RIGID PIECE IN THE FORM OF A BAR/TUBE OF PTFE WITH CARBON IN MEASUREMENTS BETWEEN 1" AND 24" IN DIAMETER AND BETWEEN 14" TO 20" IN LENGTH. | Virgin PTFE rods and tubes or with carbon fillers ranging from 1” to 24” in diameter, length from 14" to 20" with a wide range of intermediate measurements, the rods is a solid piece of PTFE while the tube has inner and outer diameter (hollow). WITH DRIVING QUALITIES | Due to its carbon content it becomes antistatic. It is good in wet use. Widely used in seals where great wear resistance under high pressure is required (piston rings for non-lubricated compressors, bearings) |
| BRONZE PTFE RODS AND TUBES | RIGID PIECE IN THE FORM OF A PTFE ROD/TUBE WITH BRONZE BETWEEN 1" AND 24" IN DIAMETER AND BETWEEN 14" TO 20" IN LENGTH. | Virgin PTFE rods and tubes or with bronze fillers ranging from 1” to 24” in diameter, length from 14" to 20" with a wide range of intermediate measurements, the rod is a solid piece of PTFE while the tube has inner and outer diameter (hollow). WITH CONDUCTIVE QUALITIES AND FLEXING RESISTANCE | It is vulnerable by some chemicals so it is not suitable for working with chlorine and some acids. Dynamic seals where high resistance to wear under high compression is required, but when chemical resistance is not important (compression rings, bearings and hydraulic systems) |
| CERAMIC PTFE RODS AND TUBES | RIGID PIECE IN THE SHAPE OF A PTFE ROD/TUBE WITH CERAMIC BETWEEN 1" AND 24" IN DIAMETER AND BETWEEN 14" TO 20" IN LENGTH. | Rods and tubes of virgin PTFE or with ceramic fillers ranging from 1” to 24” in diameter, length from 14" to 20" with a wide range of intermediate measurements, the rod is a solid piece of PTFE while the tube has inner and outer diameter (hollow). WITH HARDNESS, INSULATING QUALITIES AND LOW FRICTION COEFFICIENT | - |
| PIGMENTED PTFE RODS AND TUBES | RIGID PIECE IN THE SHAPE OF A PTFE ROD/TUBE WITH PIGMENT BETWEEN 1" AND 24" IN DIAMETER AND BETWEEN 14" TO 20" IN LENGTH. | Rods and tubes of virgin PTFE or with pigmented fillers ranging from 1” to 24” in diameter, length from 14" to 20" with a wide range of intermediate measurements, the bar is a solid piece of PTFE while the tube has a diameter interior and exterior (hole). WITH IDENTIFICATION QUALITIES | The pigment allows the part to distinguish itself from other components of the process, ideal for compression rings, expansion joints, etc. For the passage of milk, or products that may resemble PTFE in color. |
Rods and Tubes common applications
Petrochemical industry
It is used in piping components, seals and valves.
Pharmaceutical Industry
It is used in the manufacture of laboratory equipment, also for processing and packaging.
Automotive Industry
It is used in seals, gaskets and transmission systems.
